BXL-S203 Sheep-Specific Wireless Doppler Ultrasound with Rectal Probe | Veterinary Imaging

Technical Specifications

Tổng quát

• Working time: ≥5 hours

• Wireless transmission: Supported

• System language: Chinese, English

• Grayscale: 256

• Weight: 300g (including probe)

• Host size: 174 × 70 × 28 mm

• Power supply: 100–240V~0.8A

Imaging & Display

• Image display modes: B, 2B, 4B, B/M, M

• Harmonic imaging: Two levels

• Image frame rate: 60 frames per second

• Position markers: ≥60

• One-key measurement: Backfat thickness

Probe & Scanning

• Frequency: 5–10 MHz

• Scanning depth: Maximum depth of rectal linear array probe ≥27 cm

• Gain: Eight-stage adjustable (0–255)

• Dynamic range adjustment: 0–15

• Transmit power: 0–3

Storage & Playback

• Static image: Storage and preview supported

• Cine loop: Storage and playback of dynamic images ≥255 frames, expandable

Optional Configuration

• Probe: 6.5 MHz sheep rectal probe

Q1:Who are we?

A1: We are a leading manufacturer of animal ultrasound in China. We have occupied a significant share of the Chinese market since our establishment in 2014. Our products have been exported to dozens of countries in Europe and South America for a long time. Our products have good reputation for their excellent reliability and low prices.

Q2:Mode of transport

A2: Mainly by sea, usually CIF, customers bear the freight and tariffs

Q3: How to operate the equipment? Is there any operation guide or remote training?

A3: Provide video teaching, and you can provide remote online practical guidance if you don’t know how to do it

Q4: Does it support multi-language operation interface?

A4: Yes, you can freely switch between English, French, Spanish, Chinese, etc.

Q5: what is your delivery time?

A5: Small quantity (less than 10 sets) can ship to our clents within 3 working days for most of our models, large quantity (more than 30 units) is negotiable.

Q6: How to deal with equipment problems? Do you provide remote technical support?

A6: We provide remote technical support. The technicians will handle it first. If the equipment or probe is damaged, it will be replaced free of charge within the warranty period. If it exceeds the warranty period, it will be replaced at a fee.

Q7: Do you support third-party universal accessories?

A7: No

Q8: What couriers are supported?

A8: UPS, DHL, FEDEX

Q9: Do you provide customs clearance documents, certificates of origin, invoices, packing lists, etc.?

A9: Yes

Q10: Which countries and regions have local cooperative service providers?

A10: Mexico, Colombia, Argentina, India, Thái Lan, Pakistan, Peru, Uzbekistan, Sweden

Q11: Can you provide CE certification?

A11: Yes

Q12: Has the transportation insurance been purchased? What if it is damaged during transportation?

A12: It has been purchased. The express company will compensate for damage or loss during normal transportation. If it is the customer’s own freight forwarder, he will be responsible for it.

Q13: Does it support customized LOGO?

A13: It supports customization, and the delivery time is 5 đến 7 Ngày

Q14: Normal delivery time

A14: After receiving the customer’s payment information, if the non-customized logo is in stock, the factory can generally ship it within three days.

Standard Configuration
Host 1 set
Probe 1 piece
Lithium-ion battery 1piece
Adaptor 1 piece
Stylus 1 piece
Manual book 1 set
Suitcase 1 set

Optional Accessories
Ultrasound cart
Wireless keyboard
Wireless mouse
Negative pressure pump
Thermostat

Warranty Period
